Hardware
1.Integrated 10/100/1000M transceiver
2.Auto-Negotiation with Next Page capability
3.Supports PCI Express 1.1
4.Supports pair swap/polarity/skew correction
5.Crossover Detection & Auto-Correction
6.Supports 1-Lane 2.5Gbps PCI Express Bus
Embedded OTP memory
7.Transmit/Receive on-chip buffer support
8.Supports PCI MSI (Message Signaled Interrupt) and MSI-X
9.Supports 25MHz or 48MHz Oscillator
10.Supports power down/link down power saving/PHY disable mode
11.Supports EMAC-393 ECMA ProxZzzy Standard for sleeping hosts
12.Supports LTR (Latency Tolerance Reporting) and OBFF (Optimized Buffer Flush/Fill)
13.Supports 16-set 128-byte Wake-Up Frame pattern exact matching
14.Supports Microsoft WPD (Wake Packet Detection)

Notes
1. Power Supply:
(1). Only support 5v power supply. Do NOT connect 12V power source.
(2). Do NOT insert the sata power supply cable into our PCI-E card in the reverse direction.
2. Do NOT install this PCI-E card when the computer is on.
3. Please download driver before using.
4. Device Manager-Network Adapter-Realtek PCIe Family Cotroller#2.
5. Do NOT support Linux or Mac OS.
6. Important Note: Only work with PCI-E slot, Not for PCI Slot.
